AW-X2020S
Feature
1. Support various barcodes such as WeChat and Alipay
2. New decoding chip for interpreting various 1D and 2D barcodes
3. Support Chinese direct transmission of QR code
4. Plug and play, easy to set up and quickly match
5. Wire life more durable-
￥0.00￥0.00
-
Product Description
Feature
1. Support various barcodes such as WeChat and Alipay
2. New decoding chip for interpreting various 1D and 2D barcodes
3. Support Chinese direct transmission of QR code
4. Plug and play, easy to set up and quickly match
5. Wire life more durable
|
|
|
Specification ——
Performance Parameters | |
Light Sources | 617nm LED Aimer,White LED |
Supported Symbologies | 1D: EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar,Interleave 2 of 5, ITF-6, ITF-4, ISBN, ISSN, MSI-Plessey, GS1 Databar, GS1 CompositeCode, Code 11, Industrial 25, Standard 25, Plessey, Matrix 2 of 5. |
2D: QR Code, Data Matrix, PDF417, Mircor PDF417, Aztec, Maxicode, Mircor QR, Hanxin Code | |
Contrast: | ≥20% |
Scan Type | CMOS |
Resolution | 640*480 |
Scan Method | Manual/Continuous/Automatic Induction Scanning |
Scan angle | Yaw ±60°,Rotation 360°,Pitch ±60° |
Precision | ≥5mil |
Depth of scan field | EAN13 50-200mm(13mil); QR 25-240mm(20mil); |
Error Rate | Less than 1/5million |
Interface | USB-HID, USB-COM, RS232 |
Physical Parameters | |
Dimensions | 102mm*71mm*177mm |
Weight | 162.3g |
Material | ABS+PC |
Cable Length | 2M |
Environmental Parameters | |
Operating Temperature | -20℃~+50℃ |
Storage Temperature | -40℃~+70℃ |
Relative Humidity | 5%~95% RH（Non-condensing） |
Ambient lighting | 0~100000LUX |
Drop/Shock Resistance | Withstands multiple times 3meters drops to concrete |
Electrical Parameters | |
Voltage | DC5V±5% |
| Operating Current: | 170mA |
Standby Current | USB 25mA; RS232 2uA |
