Light Sources

617nm LED Aimer,White LED

Supported Symbologies

1D: EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar,Interleave 2 of 5, ITF-6, ITF-4, ISBN, ISSN,
MSI-Plessey, GS1 Databar, GS1 Composite Code, Code11, Industrial 25, Standard 25, Plessey, Matrix 2 of 5.

2D: QR Code, Data Matrix, PDF417, Aztec, Maxicode, Micor QR, Micor PDF417,Hanxin Code.

Contrast:

≥20%

Scan Type

CMOS

Resolution

640*480

Scan Method

Manual/Continuous/Automatic Induction Scanning

Scan angle

Yaw ±55°,Rotation 360°,Pitch ±55°

Precision

≥5mil

Depth of scan field

EAN13 50mm-200mm (13mil )；QR 25mm-240mm (20mil)；PDF147 30mm-130mm  (6.67mil )

Error Rate

Less than 1/5million

Interface

USB-HID

Wireless Communication:

Paring dedicated receiver: 2.4G communication
Paring Mobile Bluetooth Device: Bluetooth BLE 4.0

Wireelss transmission distance:

100-300meters (Open distance)

Storage Mode:

Offline Storage Model: When the scanner exits the connection ranfe the data is automatically stored.
Storage capacity is 512000 characters.
Inventory Storage mode: Scanner can enter inverntory mode, storage capacity is 512000 characters

Paring Mode:

One to one: One Scanner pairs one Receiver;
One scanner paired with one bluetooth mobule device

Physical Parameters

Dimensions

102mm*71mm*177mm

Weight

223.9g

Material

ABS+PC

Cable Length

1.2m

Environmental Parameters

Operating Temperature

-20℃~+50℃

Storage Temperature

-40℃~+70℃

Relative Humidity

5%~95% RH（Non-condensing）

Ambient lighting

0~100000LUX

Drop/Shock Resistance

Withstands multiple times 3meters drops to concrete

Electrical Parameters

Voltage

DC5V±5%

Lithium Battery:

2200mA can last continue work 7 hours

Charging time:

5 hours

Operating Current:

when not scanning code≥26mA;
when scanning code ≥280mA

Standby Current

0mA (Standby is to cut off battery power)

Charging Model:

Square USB charging cable, plug straight charge
