Light Sources

617nm Red visible LED

Supported Symbologies

UPC- A, UPC-E, EAN-13, EAN-8, Codabar, Code 39, Code 39 Full ASCII, China Post, Plessey, MSI, Code 93,
Code 128, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, Code 11, ISBN, SSN,

Code 32(Italian pharm code), Code 39 extended, GS1-128 and ITF-14, SISAS, GS1 Omnidirectional,
GS1 Limited, Aviation25, RSS 14.

Scan Type

2500 dpi Linear CCD Image Sensor

Scan speed

≥200times/s

Scan Method

Manual/Continuous/Automatic scanning

Scan angle

Yaw ±65°,Rotation ±30°,Pitch ±55°

Precision

≥4mil

Depth of scan field

20-280mm (0.33mm, PCS90%)

Error Rate

Less than 1/5million

Interface

USB-HID, RS232

Physical Parameters

Dimensions

102mm*71mm*177mm

Weight

165.9g

Material

ABS+PC

Cable Length

2M

Environmental Parameters

Operating Temperature

-20℃~+50℃

Storage Temperature

-40℃~+70℃

Relative Humidity

5%~95% RH（Non-condensing）

Drop/Shock Resistance

Withstands multiple times 3meters drops to concrete

Electrical Parameters

Voltage

DC5V±1%

Operating Current

Standby Current: 3uA;
Working Current: 120mA
