Support OS

Windows   / iOS / Android

Scan type

2D   image CMOS

Interface

USB-HID   USB-COM, RS232

Resolution

640 pixels(H)x 480 pixels(V)

Scan Mode

Manual/Auto   scan/ Continue Scan

Lighting Sourcing

Aiming:   625 nm LED; illumination:4000K LED

Frame rate

30fp/s

Scanning angle

Roll:   ±360°, Pitch:±55°, Skew: ±55°

Field of view

45°   horizontal, 34° vertical

Minimum Resolution

≥4mil（CODE   39）

Scan distance

EAN           20-200MM(13mil)

QR            5-170MM(20mil)

Support Symbologies

1D：UPC/EAN/JAN,UPC-A & UPC-E,EAN-8   & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII),   Codabar (NW7), Code 128 & EAN 128,Code 93, Interleaved 2 of 5   (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32   (Italian Pharmacode), etc.

2D: QR Code, Data Matrix, PDF417,   Aztec, Maxicode，Dotcode，GS1 DataBar stack，etc

Printing contrast

≥20%

Visual Indicato

Green   LED light, Buzzer, motor vibration

Memory Capacity

380000   bytes

Work frequency

2.400GHz-2.480GHz   ISM frequency

Wireless

2.4G:   100m;  Bluetooth HID/BLE/ SPP: 40m(in open air)

Paired Mode

One   to one, or one to more (Optional)

Physical

Size

Scanner:   92mm x 70mm x 179mm （L xW xH）

Weight

Scanner:   227g（with 18650 Electric core)

Material

ABS+PC, TPU

Cable Length

1.8m

Electronical

Voltage

5VDC±5

Working Current

400mA

Firmware Update

Computer   online upgrade

Scanner Material

Eco-friendly,   ABS+Rubber

Charge Mode

Wire   charging / seat charging

Battery

2000mAh,    5hours full charge, continue use over 12hours

Environmental

Operation Temperature

 -10   ℃ - 50℃

Storage Temperature

 -20   ℃ - 60℃

Humidity

5%   - 95%

Electrostatic protection:

±8   kV（Direct discharge)

Ambient lighting

0-100000LUX

Seismic resistance

1.6m

IP Level

IP42

Packing List

Barcode   scanner×1pc, USB cable×1pc,   Manul×1pc

Inner box

1pc/box,   100 x 80 x 240mm, 0.32Kg

Out box

30pcs/ctn,   560 x 380 x 370mm, 10.5Kg
