Scan mode

Push-button trigger/auto-sensing/continuous scanning

Communication interface

USB-HID /USB-COM /RS232 (optional).

Interface type

USB TYPE-B

Prompt way

Buzzer, LED light， Vibration

How it's set up

Manually scan the setting code one after the other

Housing material

ABS+PC

Cable standards

Straight line 1.6m

Exterior dimensions

194mm× 98mm×75mm (product),
230mm× 91mm×67mm (outer packing).

Weight

342.4g (NW) ;415.6g(GW).

Performance parameters

Sensors

CMOS

Resolution

640*480

Light source

LED

Scan angle

± 60°, ±60°, 360° (elevation, declination, rotation).

Scan rate

120 frames/sec

Field of view

48° (H) x 30° (V)

Print contrast

15% minimum

Decode the kind

1D: EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, GS1 Composite
2D: QR Code, Data Matrix (DM), PDF417, Micro QRCode, MaxiCode, Aztec Code, support mobile phone screen reading

Minimum resolution

1D code： 3MIL;   QR code： 5MIL

Depth of field

QR（15mil）
Data Matrix（10mil）
PDF 417(6.7miles)

5~250mm
15- 65mm
20- 100mm

EAN-13(13mil)
Code 39（8mil）
Code 128（8mil）

20~255mm
25- 155mm
25~180mm

Electrical parameters

Input voltage

DC 5V±10%

Current

Operating: 250 mAh, Standby: 113 mAh

Environmental parameters

Temperature

0°C-50°C(Working);-10°C~+60°C(Storage).

Humidity

5%-95% non-condensing

Ambient brightness

Max.5,000 Lux(fluorescence)

Ingress protection

IP65

Seismic resistance

It can withstand a 1.5m drop in the air
