Interfaces

USB+Bluetooth

Print   Comand

Support ESC/POS compatible, TSPL   instruction set

Print   Method

Direct Line Thermal

Pirnt   Speed

70mm/sec

Print   Resolution

 203 DPI

TPH   Life

50km (25% printing density or   less) or per dot: 100 million pulses

Inner   Code

ASCII font library (8x16, 12x24,   16x32, 24x48), GBK (16x16), GB1830 (24X24)

Print   content

English, Numbers, Various   symbols, Chinese characters, Graphics, Curves, Pre-stored icons

One-dimensional   code

UPC / UPC-E / CODE39 / EAN-13 /   EAN-8 / CODABAR / CODE128 / CODE93 / CODE128 / ITF

Two-dimensional   code

QR Code, PDF417

Parameter   settings

Printing parameters, Bluetooth   parameters, other parameters, etc.

Alarm

By Buzzer, paper shortage   detection, low battery detection

Black   mark detection

Yes

Label   detection

Yes

Status   indication TFT display

Communication mode,  Printing, Out of paper, Out of power,  Sleep mode,    Paper type

Paper

Thermal   Paper Types

continuous paper, label paper

Available   Rang of Paper Width

30-80mm

Roll   Diameter

φ≤50mm

Available   Printing Width

72mm  (24 Chinese characters/line 48 English   characters/line standard 24 dot matrix high font)

Paper   Thickness

 0.06-0.20 mm

Electrical

Charging   Method

 AC 100-240v 5060Hz 0.4A DC 5V 1A

Battery

DC7.4V/ 2500 mAh rechargeable   lithium battery

Charging   time

5hours full charge with standby   220hours(can print out 150m long paper with 12.5% density)

Physical

Printer   Dimension

115*110*58mm

Unit   Weight

350g （with battery)

Pieces   Per CTN

40 Pieces

Printer   Color

Black

Environmental

Operating   Temperature

 +0 ℃ ~ 50 ℃ (no condensation allowed)

Working   Humidity

20% ~ 85% RH (no condensation   allowed)

Storage   Temperature

 -20 ℃ ~ 60 ℃   (no condensation allowed)

Storage   Humidity

5% ~ 95% RH (no condensation   allowed)

Mechanical   Noise

 less than 60dB (A weighted RMS)
